Velotric Range Extender Battery

Overview

The Velotric Range Extender Battery is a power bank that gives your ride up to 30 miles of extra range and allows you to charge your bike on the go. It can be firmly installed in the bracket.

Compatibility

This Velotric Range Extender Battery is compatible with the following Ebike models:

• Velotric T1
• Velotric T1 ST

Specification

• Dimensions: 3 inch * 8.3 inch

• Waterproof Level: IPX6

• Weight: Approximately 2.867 lbs (1.3 kg)

• Maximum Output Voltage and Current: DC 42V 3A

• Rated Voltage: 36V

• Rated Capacity: 4.9Ah (176Wh)
• Charging Parameters: DC 42V 2A, approximately 3 to 4 hours (using the original Ebike charger)
• Charging Temperature: 5°C to 40°C (41°F to 104°F)
• Operating Temperature: -10°C to 40°C (14°F to 104°F)

• What's in the box:
  • Range Extender Battery
  • Range Extender Battery Bracket
  • Discharging Cable
  • Charging Cable
• The Velotric Range Extender Battery is an accessory and comes with a 1-year limited warranty.

Installation

Velotric Range Extender Battery Assembly Video

Velotric Range Extender Battery Owner Manual

Related to

• accessories
• battery
• T1
• T1ST

• Velotric T1 Range Extender Owner's Manual.pdf2 MB
